2012 TSX SE 4 DOOR 6MT INSTRUMENT PANEL GARNISH (PASSENGER SIDE) diagram
  • 001

    light assy., foot (red)

    • Part Number: 34760-TL0-E11

    '


    KA - US - 49 State Spec

    • $14.60

  • 002

    light assy., ambient (amber)

    • Part Number: 34760-TL0-G11

    '


    KA - US - 49 State Spec

    • $14.60

  • 005

    ring

    • Part Number: 39624-S2K-003

    '


    KA - US - 49 State Spec

    • $2.45

  • 007

    socket assy.

    • Part Number: 39632-SDA-L01

    '


    KA - US - 49 State Spec

    • $19.13

  • 008

    stopper, glove box lid

    • Part Number: 66418-SA5-000

    '


    KA - US - 49 State Spec

    • $3.15

  • 009

    cap, instrument panel stay

    • Part Number: 66844-SA7-000

    '


    KA - US - 49 State Spec

    • $9.25

  • 010

    pocket, center *nh525l*

    • Part Number: 77281-TL2-A01ZA

    (GUN METALLIC)

    '


    KA - US - 49 State Spec

    • $124.43

  • 011

    label, utility pocket

    • Part Number: 77288-SDA-A01

    '


    KA - US - 49 State Spec

    • $3.57

  • 013

    holder assy., center *yr381l*

    • Part Number: 77298-TL2-B21ZA

    (WOOD GRAIN)

    '


    KA - US - 49 State Spec

    • $170.60

  • 015

    cover assy., passenger (lower)

    • Part Number: 77346-TL0-G01

    '


    KA - US - 49 State Spec

    • $47.50

  • 016

    separator

    • Part Number: 77501-TL0-G02

    '


    KA - US - 49 State Spec

    • $25.45

  • 017

    lid, maintenance

    • Part Number: 77502-TL0-G01

    '


    KA - US - 49 State Spec

    • $5.65

  • 018

    arm

    • Part Number: 77504-TL0-G01

    '


    KA - US - 49 State Spec

    • $4.08

  • 019

    stopper assy., glove box

    • Part Number: 77506-TL0-G01

    '


    KA - US - 49 State Spec

    • $7.90

  • 020

    box assy., glove *nh690l*

    • Part Number: 77510-TL2-A03ZB

    (PREMIUM BLACK)

    '


    KA - US - 49 State Spec

    • $317.50

  • 021

    cylinder, glove box

    • Part Number: 77520-TL2-A01

    '


    KA - US - 49 State Spec

    • $33.22

  • 022

    damper assy., glove box

    • Part Number: 77530-TL2-A01

    '


    KA - US - 49 State Spec

    • $24.27

  • 023

    label, trunk main switch

    • Part Number: 77535-SD4-000

    '


    KA - US - 49 State Spec

    • $3.27

  • 024

    knob, glove box *nh690l*

    • Part Number: 77541-TL0-G01ZB

    (PREMIUM BLACK)

    '


    KA - US - 49 State Spec

    • $14.93

  • 025

    cap, lock (driver side)

    • Part Number: 77545-TL0-G01

    '


    KA - US - 49 State Spec

    • $3.62

  • 026

    cap, lock (passenger side)

    • Part Number: 77546-TL0-G01

    '


    KA - US - 49 State Spec

    • $3.62

  • 027

    outlet assy., r. center *nh167l*

    • Part Number: 77610-TL0-G01ZB

    (GRAPHITE BLACK)

    '


    KA - US - 49 State Spec

    • $66.67

  • 028

    outlet assy., l. center *nh167l*

    • Part Number: 77615-TL0-G01ZB

    (GRAPHITE BLACK)

    '


    KA - US - 49 State Spec

    • $66.67

  • 029

    outlet assy., r. side *nh167l*

    • Part Number: 77620-TL0-G01ZB

    (GRAPHITE BLACK)

    '


    KA - US - 49 State Spec

    • $74.03

  • 031

    pocket assy., utility

    • Part Number: 77710-TL2-A01

    '


    KA - US - 49 State Spec

    • $24.58

  • 032

    bolt-washer (5x19)

    • Part Number: 90140-SDA-A00

    '


    KA - US - 49 State Spec

    • $1.52

  • 033

    clip, snap fitting (po)(orange)

    • Part Number: 90666-TA0-A01

    '


    KA - US - 49 State Spec

    • $1.75

  • 034

    clip, snap fitting (po)(orange)

    • Part Number: 90666-TA0-A11

    '


    KA - US - 49 State Spec

    • $2.05

  • 035

    grommet, screw (4mm)

    • Part Number: 91640-SM4-003

    '


    KA - US - 49 State Spec

    • $2.38

  • 037

    screw, tapping (4x16)

    • Part Number: 93903-14480

    '


    KA - US - 49 State Spec

    • $0.55

  • 038

    screw, tapping (4x12)

    • Part Number: 93913-14220

    '


    KA - US - 49 State Spec

    • $0.55

  • 039

    screw, tapping (4x16) (po)

    • Part Number: 93913-14420

    '


    KA - US - 49 State Spec

    • $0.55

  • 040

    screw, tapping (4x12) (po)

    • Part Number: 93913-24280

    '


    KA - US - 49 State Spec

    • $1.20

  • 041

    pin, spring (4x22)

    • Part Number: 94305-40222

    '


    KA - US - 49 State Spec

    • $1.20

  • 042

    latch

    • Part Number: 77296-TL0-G01

    '


    KA - US - 49 State Spec

    • $8.33

  • 043

    light assy., foot (blue)

    • Part Number: 34760-TA0-J01

    '


    KA - US - 49 State Spec

    • $19.22

  • 043

    light assy., ambient (red)

    • Part Number: 34760-TL0-G01

    '


    KA - US - 49 State Spec

    • $11.96
