2013 ILX PRE2.4 4 DOOR 6MT ELECTRICAL CONNECTORS (FR.) diagram
  • 001

    sub-cord (1.25) (10 pieces) (red)

    • Part Number: 04320-S6M-A00

    '


    KA - US - 49 State Spec

    • $10.13

  • 002

    sub-cord (0.5) (10 pieces) (yellow)

    • Part Number: 04320-SAA-A00

    '


    KA - US - 49 State Spec

    • $10.13

  • 003

    pigtail (0.5) (10 pieces) (gray)

    • Part Number: 04320-SCK-A00

    '


    KA - US - 49 State Spec

    • $10.20

  • 004

    pigtail (0.5) (10 pieces) (gray)

    • Part Number: 04320-SJK-A00

    '


    KA - US - 49 State Spec

    • $63.95

  • 005

    sub-cord (1.25) (10 pieces) (gray)

    • Part Number: 04320-SNA-B00

    '


    KA - US - 49 State Spec

    • $29.77

  • 006

    sub-cord (1.25) (10 pieces) (red)

    • Part Number: 04320-SP0-N00

    '


    KA - US - 49 State Spec

    • $47.32

  • 007

    sub-cord (0.5) (10 pieces) (yellow)

    • Part Number: 04320-SP0-V10

    '


    KA - US - 49 State Spec

    • $4.80

  • 008

    sub-cord (1.25) (10 pieces) (gray)

    • Part Number: 04320-SWA-B00

    '


    KA - US - 49 State Spec

    • $19.88

  • 009

    sub-cord (2.0) (10 pieces) (red)

    • Part Number: 04320-TA0-B00

    '


    KA - US - 49 State Spec

    • $72.88

  • 010

    sub-cord (1.25) (10 pieces) (blue)

    • Part Number: 04320-TX6-A00

    '


    KA - US - 49 State Spec

    • $70.57

  • 011

    connector, waterproof (2p 040f) (5 pieces) (gray)

    • Part Number: 04321-S5A-305

    '


    KA - US - 49 State Spec

    • $4.97

  • 012

    connector, waterproof (2p 090f) (5 pieces)

    • Part Number: 04321-S6M-305

    '


    KA - US - 49 State Spec

    • $4.97

  • 013

    connector, waterproof (1p 090f) (5 pieces)

    • Part Number: 04321-S87-305

    '


    KA - US - 49 State Spec

    • $2.75

  • 014

    connector (2p 110f) (5 pieces)

    • Part Number: 04321-SH3-305

    '


    KA - US - 49 State Spec

    • $32.80

  • 016

    connector, waterproof (2p 090 f) (5 pieces)

    • Part Number: 04321-SNA-305

    '


    KA - US - 49 State Spec

    • $14.57

  • 017

    connector, waterproof (2p 090 f) (5 pieces)

    • Part Number: 04321-STK-305

    '


    KA - US - 49 State Spec

    • $17.50

  • 018

    connector, waterproof (2p 187f) (5 pieces)

    • Part Number: 04321-TA0-305

    '


    KA - US - 49 State Spec

    • $34.32

  • 020

    joint, terminal (0.5) (25 pieces) (yellow)

    • Part Number: 04323-SP0-A01

    '


    KA - US - 49 State Spec

    • $37.65

  • 021

    joint, terminal (1.25) (25 pieces) (red)

    • Part Number: 04323-SP0-A11

    '


    KA - US - 49 State Spec

    • $46.15

  • 022

    joint, terminal (2.0) (25 pieces) (blue)

    • Part Number: 04323-SP0-A21

    '


    KA - US - 49 State Spec

    • $39.00
