2013 TL ADV 4 DOOR 6AT A/C HOSES - PIPES diagram
Back to Top
label, air conditioner caution(hfc134a)hose, suctionhose, dischargepipe assy., a air conditionerpipe assy., b air conditionerclamp a, air conditioner pipeclamp b, air conditioner pipeclamp, receiver pipesensor assy., pressurecap, valve (h)cap, valve (l)o-ring (5/8")o-ring (5/8")o-ring (5/8")o-ring (1/2")o-ring (1/2")o-ring (8mm)o-ring (8mm)o-ring (8mm)bolt, flange (6x38) (guide)bolt, flange (6x25)clip, receiver pipeclip, receiver pipeclip, receiver pipebolt-washer (6x16)bolt-washer (6x16)screw, pan (4x8)nut, flange (6mm)bolt, flange (6x30)bolt, flange (6x25)bolt, flange (6x25)
