1997 del SI 2 DOOR 4AT TRUNK LID diagram
Back to Top
cushion, hoodskirt, rr. panel (upper)bracket, r. rr. panel skirt (upper)bracket, l. rr. panel skirt (upper)lid, trunk (dot)hinge, r. trunkhinge, l. trunkseal, fuel lid opener (green)cable, fuel lid openercushion, roof stoplock, tailgatecylinder, tailgategrommet, key cylinderstopper, r. body wedgestopper, l. body wedgerod, trunk lockweatherstrip, trunk lidcable, trunk openercover, trunk opener *nh167l*control assy., fuel remote *nh167l*knob assy., fuel *nh167l*knob assy., fuel *nh167l*knob assy., trunk opener *nh167l*cylinder, trunk remote controlbolt, lock strikershim, tailgate striker (2.0)shim, tailgate striker (1.0)cushion, tailgatescrew-washer (6x14)bolt-washer (6x15)nut, fixed torquegasket, seatplug, holesnap, tailgate lockgrommet (6mm)cushion, wire harness (50x100)cushion, wire harness (50x100)cushion, wire harness (50x100)bolt-washer (6x12)bolt-washer (6x12)bolt-washer (6x20)bolt-washer (8x20)screw, flat (6x16)screw, tapping (4x8)screw, tapping (4x8)nut-washer (8mm)plug, blind (10mm)
