View large diagramHide diagramView diagramView printable catalog
  • 001

    condenser

    • Part Number: 30510-SX0-003

    '


    KA - US - 49 State Spec

    • $9.33

  • 002

    grommet, wire harness (black)

    • Part Number: 32103-679-000

    '


    KA - US - 49 State Spec

    • $10.87

  • 003

    band, cable (90mm)

    • Part Number: 32112-S2K-003

    '


    KA - US - 49 State Spec

    • $2.12

  • 004

    band, wire harness offset (20)(122.5mm) (black)

    • Part Number: 32132-SM4-003

    '


    KA - US - 49 State Spec

    • $3.72

  • 005

    band, harness offset (10) (122.5mm) (brown)

    • Part Number: 32134-SM4-003

    '


    KA - US - 49 State Spec

    • $1.78

  • 006

    connector, diode (2p)

    • Part Number: 32146-SH3-003

    '


    KA - US - 49 State Spec

    • $12.97

  • 007

    protector, bulkhead

    • Part Number: 32202-S9A-003

    '


    KA - US - 49 State Spec

    • $7.77

  • 008

    bracket, engine room wire harness

    • Part Number: 32203-S7A-000

    '


    KA - US - 49 State Spec

    • $4.40

  • 009

    filter, noise

    • Part Number: 38617-S5A-J01

    '


    KA - US - 49 State Spec

    • $9.62

  • 010

    clip, wire harness (110mm) (7mm hole) (green)

    • Part Number: 91507-SL9-003

    '


    KA - US - 49 State Spec

    • $4.10

  • 011

    clip, wire harness (50mm) (black)(harness taping)

    • Part Number: 91507-693-003

    '


    KA - US - 49 State Spec

    • $4.55

  • 012

    clip, offset (10) (50mm) (brown)

    • Part Number: 91510-SA5-003

    '


    KA - US - 49 State Spec

    • $5.95

  • 013

    clip, wire harness (44mm) (natural)

    • Part Number: 91531-S04-003

    '


    KA - US - 49 State Spec

    • $3.05

  • 014

    clip, connector (natural)

    • Part Number: 91533-S04-003

    '


    KA - US - 49 State Spec

    • $2.25

  • 014

    clip, connector (dark green)

    • Part Number: 91565-S0X-003

    '


    KA - US - 49 State Spec

    • $2.02

  • 015

    clip, harness band (145.2mm) (natural)

    • Part Number: 91540-SV4-003

    '


    KA - US - 49 State Spec

    • $5.02

  • 016

    clip, harness band (96.9mm) (natural)

    • Part Number: 91540-S0A-003

    '


    KA - US - 49 State Spec

    • $4.00

  • 017

    clip, harness band (150mm) (natural)

    • Part Number: 91540-S6A-003

    '


    KA - US - 49 State Spec

    • $2.57

  • 018

    clip, harness band (157.7mm) (black)

    • Part Number: 91540-S7S-003

    '


    KA - US - 49 State Spec

    • $3.42

  • 019

    clip, harness band (145mm) (black)

    • Part Number: 91541-S0A-003

    '


    KA - US - 49 State Spec

    • $4.00

  • 020

    clip, harness band (140mm) (black)

    • Part Number: 91541-S6M-003

    '


    KA - US - 49 State Spec

    • $2.87

  • 021

    clip, harness band (145.2mm) (natural)(w/seal)

    • Part Number: 91545-SV4-003

    '


    KA - US - 49 State Spec

    • $5.82

  • 022

    clip, harness band (151mm) (brown)(w/seal)

    • Part Number: 91545-S2A-003

    '


    KA - US - 49 State Spec

    • $4.58

  • 023

    clip, band (6mm boss) (127mm) (natural)

    • Part Number: 91548-SV4-003

    '


    KA - US - 49 State Spec

    • $4.58

  • 024

    clip, harness band (151mm) (brown)

    • Part Number: 91551-SW5-003

    '


    KA - US - 49 State Spec

    • $4.00

  • 025

    holder, bracket (red)

    • Part Number: 91554-SM4-003

    '


    KA - US - 49 State Spec

    • $4.43

  • 026

    strap, harness (30) (107.5mm) (black)

    • Part Number: 91558-SJ6-003

    '


    KA - US - 49 State Spec

    • $2.17

  • 027

    clip, harness band (167mm) (natural)

    • Part Number: 91559-S47-003

    '


    KA - US - 49 State Spec

    • $5.02

  • 028

    clip, connector (natural)

    • Part Number: 91533-S04-003

    '


    KA - US - 49 State Spec

    • $2.25

  • 028

    clip, connector (dark green)

    • Part Number: 91565-S0X-003

    '


    KA - US - 49 State Spec

    • $2.02

  • 029

    clip, wire harness (130mm) (natural)

    • Part Number: 91571-S10-003

    '


    KA - US - 49 State Spec

    • $4.58

  • 031

    cushion, wire harness (50x100)

    • Part Number: 91902-SB2-003

    '


    KA - US - 49 State Spec

    • $4.60

  • 032

    plaster, wire harness (50x100)

    • Part Number: 91902-S2X-003

    '


    KA - US - 49 State Spec

    • $2.23

  • 033

    plaster, wire harness (50x50)

    • Part Number: 91902-S3N-003

    '


    KA - US - 49 State Spec

    • $1.43

  • 034

    bolt-washer (6x16)

    • Part Number: 93403-06016-08

    '


    KA - US - 49 State Spec

    • $1.02

  • 035

    plug, blind (30mm)

    • Part Number: 95550-30000

    '


    KA - US - 49 State Spec

    • $3.32
