• 001

    hose, fuel feed

    • Part Number: 16720-PHM-A02

    '


    KA - US - 49 State Spec

    • $136.35

  • 002

    stay, fuel hose clamp (a)

    • Part Number: 16724-PHM-A00

    '


    KA - US - 49 State Spec

    • $4.42

  • 003

    cover a, fuel connector

    • Part Number: 16725-RBA-J00

    '


    KA - US - 49 State Spec

    • $3.23

  • 004

    clamp, fuel hose (black)

    • Part Number: 16727-PND-004

    '


    KA - US - 49 State Spec

    • $2.43

  • 005

    canister assy.

    • Part Number: 17011-S5B-L00

    '


    KA - US - 49 State Spec

    • $349.08

  • 006

    valve assy., canister vent shut

    • Part Number: 17311-SDC-L02

    '


    KA - US - 49 State Spec

    • $138.12

  • 007

    cap

    • Part Number: 17312-SDC-L01

    '


    KA - US - 49 State Spec

    • $4.57

  • 008

    filter, canister

    • Part Number: 17315-SHJ-A01

    '


    KA - US - 49 State Spec

    • $60.58

  • 009

    retainer

    • Part Number: 17321-SDA-A01

    '


    KA - US - 49 State Spec

    • $1.38

  • 010

    bracket, canister

    • Part Number: 17358-S3Y-A50

    '


    KA - US - 49 State Spec

    • $368.40

  • 011

    bolt, canister mounting (8mm)

    • Part Number: 17359-SDA-A01

    '


    KA - US - 49 State Spec

    • $3.95

  • 012

    tube a, drain

    • Part Number: 17372-S3Y-A50

    '


    KA - US - 49 State Spec

    • $10.85

  • 013

    tube b, drain

    • Part Number: 17374-S3Y-A50

    '


    KA - US - 49 State Spec

    • $26.92

  • 014

    tube assy., pressure sensor

    • Part Number: 17382-S3Y-A50

    '


    KA - US - 49 State Spec

    • $6.87

  • 015

    pipe, fuel feed

    • Part Number: 17700-S3Y-A51

    '


    KA - US - 49 State Spec

    • $47.23

  • 016

    rubber, fuel pipe insulator

    • Part Number: 17701-S3Y-000

    '


    KA - US - 49 State Spec

    • $3.82

  • 017

    retainer (white) (sanoh)

    • Part Number: 17711-S0X-004

    '


    KA - US - 49 State Spec

    • $5.62

  • 018

    retainer (white) (sanoh)

    • Part Number: 17711-S84-004

    '


    KA - US - 49 State Spec

    • $1.78

  • 019

    pipe, fuel purge

    • Part Number: 17720-S3Y-A51

    '


    KA - US - 49 State Spec

    • $53.12

  • 020

    pipe a, purge joint

    • Part Number: 17731-S3Y-A50

    '


    KA - US - 49 State Spec

    • $21.58

  • 021

    hose assy., purge (d)

    • Part Number: 17734-S3Y-A51

    '


    KA - US - 49 State Spec

    • $24.22

  • 022

    hose assy., purge (a)

    • Part Number: 17735-S3Y-A51

    '


    KA - US - 49 State Spec

    • $16.42

  • 023

    hose assy., purge (b)

    • Part Number: 17736-S3Y-A51

    '


    KA - US - 49 State Spec

    • $16.75

  • 024

    stay e, fuel pipe

    • Part Number: 17760-S3Y-020

    '


    KA - US - 49 State Spec

    • $5.55

  • 025

    stay a, fuel pipe

    • Part Number: 17761-S3Y-A01

    '


    KA - US - 49 State Spec

    • $5.03

  • 026

    stay b, fuel pipe

    • Part Number: 17762-S3Y-000

    '


    KA - US - 49 State Spec

    • $4.30

  • 027

    stay c, fuel pipe

    • Part Number: 17763-S3Y-000

    '


    KA - US - 49 State Spec

    • $4.30

  • 028

    stay d, fuel pipe

    • Part Number: 17764-S3Y-000

    '


    KA - US - 49 State Spec

    • $5.03

  • 029

    stay f, fuel pipe

    • Part Number: 17766-S3Y-A50

    '


    KA - US - 49 State Spec

    • $9.12

  • 030

    stay, purge joint

    • Part Number: 36165-PHM-A00

    '


    KA - US - 49 State Spec

    • $42.12

  • 031

    joint, purge

    • Part Number: 36166-RJA-A01

    '


    KA - US - 49 State Spec

    • $9.38

  • 032

    sensor, vent pressure

    • Part Number: 37940-SDA-A01

    '


    KA - US - 49 State Spec

    • $69.22

  • 033

    nut, flange (6mm)

    • Part Number: 90301-SE0-J00

    '


    KA - US - 49 State Spec

    • $2.58

  • 034

    o-ring (9.8x2.4)

    • Part Number: 91305-PMS-A01

    '


    KA - US - 49 State Spec

    • $8.20

  • 035

    o-ring

    • Part Number: 91391-SDC-L01

    '


    KA - US - 49 State Spec

    • $3.80

  • 036

    o-ring

    • Part Number: 91394-SDA-A01

    '


    KA - US - 49 State Spec

    • $1.97

  • 037

    clamp, tube (d13.0)

    • Part Number: 91408-SDB-000

    '


    KA - US - 49 State Spec

    • $2.18

  • 038

    clamp, fuel tube (d15.5)

    • Part Number: 91412-SDC-L01

    '


    KA - US - 49 State Spec

    • $1.72

  • 039

    clamp, fuel pipe

    • Part Number: 91592-S3Y-013

    '


    KA - US - 49 State Spec

    • $2.33

  • 040

    clamp b, fuel pipe

    • Part Number: 91596-S3Y-A51

    '


    KA - US - 49 State Spec

    • $3.83

  • 041

    clamp c, fuel tube

    • Part Number: 91597-S3Y-A51

    '


    KA - US - 49 State Spec

    • $3.83

  • 042

    clamp, fuel pipe

    • Part Number: 91598-S3Y-A51

    '


    KA - US - 49 State Spec

    • $3.98

  • 043

    rubber e, fuel pipe insulator

    • Part Number: 91599-SDA-A00

    '


    KA - US - 49 State Spec

    • $27.18

  • 044

    clamp e, fuel pipe

    • Part Number: 91599-S3Y-003

    '


    KA - US - 49 State Spec

    • $4.00

  • 045

    bolt-washer (6x16)

    • Part Number: 93403-06016-08

    '


    KA - US - 49 State Spec

    • $1.02

  • 046

    bolt-washer (6x16)

    • Part Number: 93405-06016-05

    '


    KA - US - 49 State Spec

    • $1.02

  • 047

    bolt-washer (6x16)

    • Part Number: 93405-06016-08

    '


    KA - US - 49 State Spec

    • $1.02

  • 048

    nut, flange (6mm)

    • Part Number: 94050-06080

    '


    KA - US - 49 State Spec

    • $0.23

  • 049

    nut, flange (8mm)

    • Part Number: 94050-08040

    '


    KA - US - 49 State Spec

    • $0.82

  • 050

    bolt, flange (6x8)

    • Part Number: 95701-06008-08

    '


    KA - US - 49 State Spec

    • $0.88

  • 051

    bolt, flange (6x12)

    • Part Number: 95701-06012-05

    '


    KA - US - 49 State Spec

    • $0.88
