SLIDING ROOF
View large diagramHide diagramView diagramView printable catalogTranslate
2008 civic SI(SUM TIRE) 2 DOOR 6MT SLIDING ROOF diagram

  • 001

    clip, oil drain tube

    Part Number: 15707-634-000

    ''


    KA - US - 49 State Spec

    • $3.85

  • 002

    clip, air hose (16mm)

    Part Number: 18534-634-670

    ''


    KA - US - 49 State Spec

    • $4.18

  • 003

    tube, fr. drain (sunroof)

    Part Number: 70050-SVA-A00

    ''


    KA - US - 49 State Spec

    • $7.82

  • 004

    valve, drain (sunroof)

    Part Number: 70052-SJD-J00

    ''


    KA - US - 49 State Spec

    • $8.50

  • 005

    valve, fr. drain (sunroof)

    Part Number: 70052-S6A-J00

    ''


    KA - US - 49 State Spec

    • $7.67

  • 006

    tube, r. rr. drain (sunroof)

    Part Number: 70060-SVA-A00

    ''


    KA - US - 49 State Spec

    • $5.97

  • 007

    tube, l. rr. drain (sunroof)

    Part Number: 70065-SVA-A00

    ''


    KA - US - 49 State Spec

    • $7.07

  • 008

    seal a, frame

    Part Number: 70081-SDA-A01

    ''


    KA - US - 49 State Spec

    • $5.83

  • 009

    seal b, frame

    Part Number: 70082-SDA-A01

    ''


    KA - US - 49 State Spec

    • $5.83

  • 010

    frame, sunroof

    Part Number: 70100-SVA-A01

    ''


    KA - US - 49 State Spec

    • $497.45

  • 011

    glass assy., roof

    Part Number: 70200-SVA-A01

    ''


    KA - US - 49 State Spec

    • $677.03

  • 012

    grommet, screw (4mm)

    Part Number: 70225-SDA-A01

    ''


    KA - US - 49 State Spec

    • $4.98

  • 013

    sunshade assy. *nh220l*

    Part Number: 70600-SVA-A01ZA
    (CLEAR GRAY)

    ''


    KA - US - 49 State Spec

    • $204.97

  • 014

    handle, sunshade *nh220l*

    Part Number: 70611-S5A-J01ZA
    (CLEAR GRAY)

    ''


    KA - US - 49 State Spec

    • $3.98

  • 015

    screw, tapping (4x7) (po)

    Part Number: 70617-S5A-J01

    ''


    KA - US - 49 State Spec

    • $4.55

  • 016

    cap, stay cover

    Part Number: 70623-SM4-003

    ''


    KA - US - 49 State Spec

    • $2.92

  • 017

    cover, r. link

    Part Number: 70630-SVA-A01

    ''


    KA - US - 49 State Spec

    • $11.48

  • 018

    cover, l. link

    Part Number: 70635-SVA-A01

    ''


    KA - US - 49 State Spec

    • $11.48

  • 019

    bolt, ground (6x16)

    Part Number: 90148-SH3-003

    ''


    KA - US - 49 State Spec

    • $3.85

  • 020

    bolt-washer (6x16)

    Part Number: 93405-06016-08

    ''


    KA - US - 49 State Spec

    • $1.05

  • 021

    screw, tapping (4x10)

    Part Number: 93911-14180

    ''


    KA - US - 49 State Spec

    • $0.45
